ODM Low-volume fluid AG-700 screw valve for Automated glue application system Product, Service
1 / 1
ODM Low-volume fluid AG-700 screw valve for Automated glue application system Product, Service

ODM Low-volume fluid AG-700 screw valve for Automated glue application system Product, Service

Size L225*W45*H52mm(Valve Body, without Needle Tip)

Weight 800g

Send Inquiry

Product Description

Product Details & Description

AG-7000 single-component screw valve is engineered for a variety of high-precision quantitative delivery occasions. It utilizes high-precision servo motor drive and high-precision screw feeding to ensure that the adhesive can be continuously and stably output.

The AG-700 is an advanced screw-driven dispensing valve designed for high-viscosity fluids requiring exceptional accuracy. Combined with its programmable controller, it delivers reliable, pulsation-free material deposition for demanding industrial applications.

Features & Benefits
  • High-precision servo motor drive and high precision screw feeding.
  • Dispensing with zero pulling and no dripping.
  • Simple controller interface with a variety of optional modes.
  • Corrosion-resistant stator media for an extended service life.
  • Smooth, consistent flow that eliminates air bubbles.
  • Adjustable screw speed for absolute volume control.
  • Quick disassembly design for easy cleaning and material changes.
  • Durable construction featuring stainless steel and hardened components.
Operational Compatibility
  • Platform Compatibility: Suitable for a variety of dispensing platforms (in-line or off-line).
  • Minimum Spit Amount: 0.008ml.
  • Maintenance: Offline cleaning takes approximately 10 minutes.
  • Cleaner: Solvents compatible with dispensing fluids (developed by material suppliers).
  • Viscosity Compatibility: 1 ~ 100,000 mPa (cps) / 5,000 ~ 500,000 cP.

Key Specifications (AG-700)

Specification Parameter Details / Value
Valve Type Motorized screw valve
Dispensing Range 0.001 – 500 mL/min
Max Pressure 1.2 MPa
Fluid Viscosity 5,000 – 500,000 cP
Repeatability ±1%
Controller Touchscreen with preset recipes & I/O control

Application Areas & Industries

Automotive Industry Electronics Industry Food Industry Pharmaceutical Industry Aerospace Biotechnology Renewable Energy Battery Sealing Structural Adhesives Potting & Encapsulation Solar Panel Sealing Gasketing & Heavy-Duty Bonding
Typical Applications
  • Electronics: Potting, encapsulation, underfill
  • Automotive: Battery sealing, structural adhesives
  • Energy: Solar panel sealing, fuel cell assembly
  • Industrial: Gasketing, heavy-duty bonding
Competitive Advantages
  • Zero Waste: Precise shutoff prevents material leakage
  • Adaptable: Handles fill, dot, and bead patterns
  • Low Maintenance: No seals to replace
  • Smart Integration: Compatible with robots and PLCs
Frequently Asked Questions
What is the minimum dispensing quantity of the AG-7000 screw valve?
The minimum amount of glue spit for the AG-7000 single-component screw valve is 0.008ml, making it ideal for high-precision quantitative delivery.
What range of fluid viscosities can these screw valves handle?
The valve system is highly compatible with fluid viscosities ranging from 1 to 100,000 mPa (cps) for general applications, and up to 5,000 to 500,000 cP specifically for the AG-700 model.
How long does the maintenance and offline cleaning take?
Offline cleaning and maintenance are quick and easy, taking approximately 10 minutes using solvents compatible with the dispensing fluids.
What makes these valves suitable for automation and robotic integration?
Both valves are designed for smart integration and are compatible with robots and PLCs. The controller features a touchscreen interface with preset recipes and I/O control capabilities.
How do these valves prevent material waste and dripping?
The high-precision servo motor drive and precise screw feeding mechanism ensure a stable, continuous output, eliminating pulling, dripping, and material leakage.
